ZPX conceals all cables through the entire length of the post in contrast to competitive systems that “clip” the cables to the rear of the post, which can look messy and disorganized.
Each arm holds up to 24.3 pounds allowing the same arm to support all your displays up to 38” monitors. Overall, ZPX supports up to 90 lbs of monitors in the same monitor support solution.
Easily installs and upgrades by adding additional monitors without disturbing the original setup – from 1 to 9 monitors
Easily installs and upgrades by adding additional monitors without disturbing the original setup – from 1 to 6 monitors
Each arm holds up to 24.3 pounds allowing the same arm to support all your displays up to 38” monitors. Overall, ZPX supports up to 90 lbs of monitors in the same monitor support solution.
ZPX conceals all cables through the entire length of the post in contrast to competitive systems that “clip” the cables to the rear of the post, which can look messy and disorganized.
Maximum Arm Weightload: | 24.3 lbs |
Maximum Post Weightload: | 90 lbs |
Arm Support: | Up to 3 monitor per row, 2 rows, 6 monitors |
Monitor Height Adjustment Range: | Total: 11.7”, 5.9” above and 5.8” below mounting point |
Monitor Depth Adjustment Range: | 24.9” fully extended to 3.4” in front of post |
Arm Length: | Straight: 13.9” Straight/Straight: 24.3” Straight/Dynamic: 24.9” |
Post diameter: | 1.7” |
Monitor Mount (Shoulder) Length: | Centerpoint of post to centerpoint of arm insert: 2.8” |
Post Heights: | 12” for single Row, 24” for Dual Row |
Zslider VESA Plate Adjustment: | 4.4” of lateral adjustment at end of arm |
Mounts Available: | Clamp Mount, Sliding Desk Clamp Mount,
Bolt-Through Mount, Rail Mount |
Monitor Support Brackets: | Individual “Shoulders” slide vertically along full length of post and lock into place tool-lessly using a locking lever |
Cable Management: | Full length of post, with slotting for ease of installation or removal Full length of each Monitor Arm link, with easy access to right and left for installation or removal |
Materials: | Aluminum, ABS, POM, Nylon and Steel |
Sustainability: | 29% recycled and 99% recyclable content |
Installation Tools placement: | Hidden in the top post, suspended from top cap |
Warranty: | Limited 10-year warranty for 24/7 usage |
Zgonic, originating in Australia in 2011, is the world’s leader in Workspace Technology, a discipline which focuses on providing more effective use of technology in the workplace. We blend state-of-the-art workstation performance with exciting new design elements.
